Conext MPPT 100 600: 6kW Solar PV Charge Controller
This product is discontinued for the EMEA market. For technical support, please visit here.
Optimum system performance and flexibility with DC coupled solar with storage
Part number: 865-1034
- MPPT 100 600 and MPPT 80 600 Datasheet Download
- MPPT-100-600-y-80-600-ficha-técnica Download
- Optimisation PV MPPT Controleurs de charge solaire 600 Vcc Download
- MPPT PV Optimierung 600 VDC Solarladeregler Download
- Ottimizzazione fotovoltaica MPPT Controllori di carica solare a 600 VCC Download
- 600 VDC ladingcontrollers voor zonne energie Download
- Conext-MPPT-80-MPPT-100-Shade-Tolerant-Maximum-Power-Point-Tracking-Whitepaper_ENG Download
- HVMPPT_CAD_210-3082-01-01_Rev-A.igs_ Download
The Conext™ MPPT 100 A 600 Vdc solar charge controller offers optimum system performance for DC coupled solar and storage installations, with easy, flexible installation of large PV arrays. With up to 6 kW of charging power, and allowance for over-sized arrays, the MPPT 100 is ideal for residential grid tied self-supply and off-grid systems and is scalable for larger installations. The MPPT 100 600 offers faster installations and lower balance of system costs with 2 string installations and is compatible with Conext XW and SW storage inverter solutions.
Why Choose Conext MPPT 100 600: 6kW Solar PV Charge Controller
Optimum System Performance
- High power, 600 Vdc MPPT charge controller for DC coupled solar and storage
- 100A rating for output charging power up to 6 kW
- Flexibility for oversized PV array power ratings e.g. 7 kW or more
- Ideal for grid tied self-supply and off-grid systems with high PV to battery to grid efficiency
- Ability to recharge dead batteries from solar, providing maximum energy resilience for longer duration grid outages
- Harvest more energy with shade tolerant fast sweep MPPT algorithm
Flexible
- Flexible string sizing with a wide MPPT and PV operating voltage range
- Compatible with all brands of PV Modules and wide range of 24 V and 48 V battery technologies
- Stand-alone application or integration with XW Pro, XW+ and SW series storage inverters for a complete solar and storage solution
Easy to install
- 2 string installations and smaller wire sizing with 600 Vdc PV arrays, allowing faster, lower cost installations
- No need for a combiner box with DC breakers or fuses
- Easy to install PV disconnect and NEC 2017 compliant rapid shutdown transmitter with the MPPT Disconnect RS accessory, UL1741 PVRSS certified
Compatible with Insight Energy Management
- Setup and configuration
- Remote monitoring & control with advanced data security
- Web and mobile app
- Multi-site management for installers
